BUCKING SERVICES

TEK Engineering's fully rotational torque (RT) bucking machine is designed for fast and accurate makeup and breakout of premium and non-premium threaded tubular equipment. The machine can handle up to a maximum torque of 100,000 ft-lb tracking thread, and run in from as low as 200 ft-lb.

The self-contained, free-standing, hydraulically powered torque machine consists of a fixed headstock and a traversing tailstock, with a hinged top-opening feature to help ensure tools are loaded safely and efficiently.

The stocks feature hydraulically controlled clamp cylinders that can go from 2 3/8 to 22 in. OD, without the need to change jaws between sizes.

Features

• Accurate Torque Turn graph reports for full authentication and traceability
• Calibrated to thread manufacturers’ guidelines and tolerances
• Fully floating head and tailstock to accommodate offset connections
• Traversing tailstock, top-opening feature ensuring tools are loaded safely
• Soft Jaws for use with Chrome and CRA Tubulars.
• Serviced with 20T overhead crane

In addition to the RT Bucking machine TEK Engineering provides a range of bespoke makeup solutions enabling various assemblies including 42” Hole Opener BHA’s, Wellheads, and Surface Flow Trees to be handled off the critical path.

TEK Engineering has the Engineering support, Technical Expertise and Operational flexibility to meet your offline makeup requirements so contact us to see how we can be of assistance.
